Technical Info
Performance Information
Cooling Capacity: 575.8 kW
Total Compressor Power: 183.4 kW
Total Fan Motor Power: 7.97 kW
Total Unit Power: 192.5 kW
Efficiency: 2.99 kW/kW
A-Weighted Sound Power Level: 95 dbA
Refrigerant: R134A
Evaporator Information
Fluid Type: Fresh Water
Fouling Factor: 0.0180 (sqm-K)/kW
Number of Passes: 2
Leaving Temperature: 6.0 °C
Entering Temperature: 12.0 °C
Fluid Flow: 22.91 L/s
Total Pressure Drop: 30.1 kPa
Condenser Information
Altitude: 0 m
Number of Fans: 11
Total Condenser Fan Air Flow at 20°C: 37583 L/s
Entering Air Temperature: 35.0 °C
